Provides a detailed output of AVB streams and reservations on the network. Provides a brief view of AVB streams on the network. Displays stream reservation domain active ports, gPTP neighbor delay and VLAN membership.ĭisplays a high level overview of all AVB streams advertised on the network. Shows a high level overview of AVB operation on the switch. The following commands are used to view the status of AVB on the switch and for assisting with diagnosing issues. Please see the IOS XE command reference guides for further details. Many other specific configuration options are available for the AVB protocols. Connected AVB enabled end points will begin transmitting protocol messages within moments of configuring the switch. Switch(config-if-range)#power inline port 2-event The following is an example for configuring all ports 1-24 using the interface range command, 2-event POE configuration with additional easy to identify interface description of BIAMP on the ports: Note that power budget allocation for a class-4 device will be 30W when 2-event classification is enabled on the port otherwise it will be 15.4W. Step 3 - Optional Configuration of interfaces connecting to devices requiring class 4 (POE+ and PPoE).īiamp class 4 devices will require additional 2-event classification commands to negotiate with Cisco Power Sourcing Equipment (PSE).Ĭisco indicates 2-event classification allows class 4 Powered devices (PDs) to detect a PSE capability of providing 30W from hardware then register itself moving upward to PoE+ level without waiting for any CDP/ LLDP packet exchange.Īfter 2-event is enabled on a port, you must manually shut / un-shut the port or re-connect the PD again to re-start the IEEE detection process. Switch(config-if-range)#ptp sync interval -2 Switch(config-if-range)#spanning-tree portfast trunk Switch(config-if-range)#switchport mode trunk Switch(config)#interface range GigabitEthernet1/0/1 - 24 The following is an example for configuring all ports 1-24 using the interface range command: Set PTP sync interval to be suitable for AVB end points.Įnsure the port is not administratively shut down.Įnd configuration mode and return to EXEC mode.Ĭonfiguring port by port is time consuming. Interface moves directly to spanning-tree forwarding state Switch(config-if)# spanning-tree portfast t runk Switch(config)# interface GigabitEthernet1/0/1
The following commands show enabling trunk mode for interface GigabitEthernet1/0/1. The port must also not be administratively shutdown. Step 2 - Configure interfaces with AVB connections to VLAN trunk mode.Īny ports with AVB devices attached must be configured for VLAN trunking mode. In these cases, VLAN 2 (or any nominated VLAN) can be configured manually and MVRP not utilized.īiamp AVB devices will honor what is requested by the switch.įor further details, see the Cisco IOS XE command reference guide for configuring Audio Video Bridging. MSRP optimization command requested by CiscoĮnd global configuration mode and return to EXEC mode.Īutomatic VLAN creation may not be preferred some environments. QOS increase this buffer requested by Cisco Switch(config)# qos queue-softmax-multiplier 1200 Set MSRP leave-all timer to expected value Switch(config)# avb msrp-leaveall-timer 25000 Switch(config)# avb msrp-leave-timer 1200 VLAN Trunking Protocol (VTP) can be configured for off or transparent mode operation. Default VLAN 1 must be enabled on AVB portsĮnter the following commands to enable AVB and MVRP (automatic VLAN) on the switch.Interfaces are not configured for Etherchannel.User has access to CLI with configure permissions.Switches have appropriate license levels.
#How to enable right to use license on cisco software#
Cisco IOS XE Software with AVB support.IOS XE Amsterdam-17.3.3 for the Catalyst 9000 family.IOS XE Gibraltar-16.12.5b for Catalyst 3000 family.DNA Subscription license not required for AVB support.Ĭisco recommends the following Cisco IOS® XE Software release versions are required for AVB support.
#How to enable right to use license on cisco series#
C9300-48UN only ports 1-36, 38 support PTP.Ĭatalyst 36 series switches have been certified by the Avnu Alliance.Ĭatalyst 93 series switches have been certified by the Avnu Alliance.NOTE: The following Cisco models PTP is not supported on all ports. Please always reach out to Cisco Support regarding information about their latest software updates. Please always check Cisco AVB for updates on their current models. AVB is supported on select models of the following Catalyst series.
